Domino 61 R272
Telefunken Italia, Milano
- Country
- Italy
- Manufacturer / Brand
- Telefunken Italia, Milano
- Year
- 1960 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 145202
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 120; 140; 160; 180; 220-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Domino 61 R272 - Telefunken Italia, Milano
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 490 x 270 x 210 mm / 19.3 x 10.6 x 8.3 inch
- Notes
-
Onde Medie e Modulazione di frequenza. Poteva ricevere anche le trasmissioni audio TV. Tasti TV1+MF canali A e B. Tasti TV2+MF canali D E F G H. Antenna a dipolo interna e presa per antenna esterna bilanciata 300 Ω e coassiale 75 Ω.
Controllo toni alti e bassi. Ingresso per giradischi.
- Net weight (2.2 lb = 1 kg)
- 5.6 kg / 12 lb 5.4 oz (12.335 lb)
- Author
- Model page created by Claudio Romanato. See "Data change" for further contributors.
