• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1951–1953

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 19166

• Number of Tubes
• 7

• Valves / Tubes
• EF12K EF12 EF12 EF12 EL12spez EL12spez AZ12

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 25 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Ela V25/1283 - Telefunken Deutschland TFK,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 535 x 250 x 190 mm / 21.1 x 9.8 x 7.5 inch

• Notes
• 3 Eingänge, 2 Ausgänge.

• Net weight (2.2 lb = 1 kg)
• 15 kg / 33 lb 0.6 oz (33.04 lb)

• Price in first year of sale
• 725.00 DM

• External source of data
• Erb

• Source of data
• Kat.d.Rundf.GrossH.1951/52
