• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1959/1960

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 101863

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• PCC88 PCF82 EF80 EF80 EF80 PCL84 ECH81 EF80 PCL82 ECH81 PCL82 PL36 PY88 DY86 EAA91 AW43-88

• Number of Transistors

• Semiconductors
• OA180 OA172 OA172 OA160 OA161 OA161 E220C5 76326

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: FE18/43T - Telefunken Deutschland TFK,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 530 x 440 x 350 mm / 20.9 x 17.3 x 13.8 inch

• Notes
• VHF; Mehrpreis für eingebauten UHF-Tuner: 110,- DM.

• Net weight (2.2 lb = 1 kg)
• 21 kg / 46 lb 4.1 oz (46.256 lb)

• Price in first year of sale
• 728.00 DM

• Source of data
• HdB d.Rdf-& Ferns-GrH 1959/60

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
