• Year
  • 1968
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 326884

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 10
  • Number of Transistors
  • 13
  • Main principle
  • Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 127; 220 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Festival FE-128 /19 - Telefunken Radiotécnica
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • Telefunken Radiotécnica Ibérica, S.A., Festival FE-128 /19

    TV B/N 19" con sintonizador toda banda transistorizado para VHF/UHF

    • Seis presintonías por botonera
    • Altavoz elíptico de 6" X 8"
    • Altavoz elíptico de 2,5" x 3,5"

    Véase mismo modelo en 23" Cruz del Sur FE-128 /23

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
