• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1955–1958

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 21451

• Number of Tubes
• 5

• Valves / Tubes
• EF41 ECH42 EAF42 EF41 EL41

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 4 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: ID61 - Telefunken Deutschland TFK,

• Shape
• Chassis only or for «building in»

• Notes
• 2-teilig. Technisch wie ID11, jedoch normale Skala.

• Price in first year of sale
• 257.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1957/58
