• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1972–1976

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 127196

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Liftomat S - Telefunken Deutschland TFK,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 385 x 120 x 260 mm / 15.2 x 4.7 x 10.2 inch

• Notes
• 3 Geschwindigkeiten; Stereo-Kristallsystem T25/1 mit Saphir A25/1. Stereo-NF-Verstärker mit 2 Endstufen je 6 W; zwei Lautsprecherboxen gehören zum Lieferumfang.

• Net weight (2.2 lb = 1 kg)
• 5.3 kg / 11 lb 10.8 oz (11.674 lb)

• Source of data
• Handbuch VDRG 1972/1973

• Mentioned in
• Handbuch VDRG 1973/1974 (bis 1975/76)

• Literature/Schematics (1)
• Trader Service Sheet 3157 / 1974

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
