• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1959–1961

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 22492

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• EF86 ECC83 EL95 EM84

• Number of Transistors
• 1

• Semiconductors
• OC603 B250C65 E30C5

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 50Hz, 110; 127; 150; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 2.5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Magnetophon 76T - Telefunken Deutschland TFK,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 309 x 147 x 234 mm / 12.2 x 5.8 x 9.2 inch

• Notes

• Vierspur; 4,75/9,5 cm/s. Spulen-Ø 15 cm. T= Tischmodell ohne eingeb. Lautsprecher.
  Umrüstbar zum Betrieb an Wechselstrom 60 Hz.

  Siehe auch: AEG Magnetophon 76T.

• Net weight (2.2 lb = 1 kg)
• 7.5 kg / 16 lb 8.3 oz (16.52 lb)

• Price in first year of sale
• 479.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1959/60

• Mentioned in
• HdB d.Rdf-& Ferns-GrH 1960/61

• Literature/Schematics (1)
• Handbuch RFP 1959/60 (Verlag Thiele, Helmstedt)
