- Country
- Germany
- Manufacturer / Brand
- Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
- Year
- 1960–1963
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 24235
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 11
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder; Radio Control (+Remote Wire etc)
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
- Loudspeaker
- 4 Loudspeakers
- Power out
- 6 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Magnetophon M24KL - Telefunken Deutschland TFK,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 630 x 270 x 530 mm / 24.8 x 10.6 x 20.9 inch
- Notes
- Zweispur; Bandgeschwindigkeiten: 9,5/19 cm/s; Spulen-Ø 22 cm.
Parallelgerät zu: AEG Magnetophon M24KL.
- Net weight (2.2 lb = 1 kg)
- 30 kg / 66 lb 1.3 oz (66.079 lb)
- Price in first year of sale
- 1,995.00 DM
- External source of data
- Erb
- Source of data
- HdB d.Rdf-& Ferns-GrH 1960/61
