Mignonette

• Country
• Italy

• Manufacturer / Brand
• Telefunken Italia, Milano

• Year
• 1951 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 101095

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AT6 50B5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• AC/DC-set / 110; 125; 140-160 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mignonette - Telefunken Italia, Milano

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Notes

• Stesso chassis dei modelli T51 e T52.
  Chassis identical to models T51 and T52.
  Sintonia ad induttori variabili.

  Il telaio è sempre collegato alla rete elettrica sia in funzionamento CC che CA. Non tutti i casi sono dichiarati poichè spesso chi propone il modello non lo può sapere.

• Literature/Schematics (1)
• Schemi di apparecchi radio ( Ravalico 1953 ) (pag. 333)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
