• Country
• Italy

• Manufacturer / Brand
• Telefunken Italia, Milano

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 96439

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH81 EABC80 ECC85 EF89 EL84 UY85

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 120-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mignonette 36 R546 - Telefunken Italia, Milano

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 360 x 200 x 180 mm / 14.2 x 7.9 x 7.1 inch

• Notes
• altoparlante ellittico 14,5x10 cm

• Source of data
• - - Data from my own collection

• Author
• Model page created by Pierantonio Ganazzin. See "Data change" for further contributors.

• Other Models

• Here you find 287 models, 242 with images and 201 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Telefunken Italia, Milano
