• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1971/1972

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 126666

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors
• BC149 BC148 AC175 AC117

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 4 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Musikus 208V - Telefunken Deutschland TFK,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 385 x 220 x 260 mm / 15.2 x 8.7 x 10.2 inch

• Notes
• 3 Geschwindigkeiten; Kristallsystem T25/1 mit Saphir A25/1.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Source of data
• Handbuch VDRG 1971/1972

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
