Pal Color Chasis Modular Ch= 712
Telefunken Radiotécnica Ibérica; Getafe
- Country
- Spain
- Manufacturer / Brand
- Telefunken Radiotécnica Ibérica; Getafe
- Year
- 1977
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 314950
Imagen del manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- A66-500X
- Number of Transistors
- Semiconductors present.
- Main principle
- Superhet with RF-stage; ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 7 W (10 W max.)
- from Radiomuseum.org
- Model: Pal Color Chasis Modular Ch= 712 - Telefunken Radiotécnica
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Telefunken Radiotécnica Ibérica Pal Color Chasis Modular Ch =712
- Sintonizador electrónico VHF/UHF tipo ET176K68
- Mando a distancia por ultrasonidos.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
