• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1969

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 174349

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• PL508 ECH84 PL509 PY500A A63-120X or A63-11X

• Number of Transistors
• 48

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: PALcolor 719T Ch= FS69-4709 - Telefunken Deutschland TFK,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 730 x 510 x 550 mm / 28.7 x 20.1 x 21.7 inch

• Notes
• Telefunken PALcolor 719T;
  63 cm PAL Farbfernsehgerät mit 6 Programm VHF & UHF Tuner nach CCIR B/G, 1 IC, 67 Dioden, Ausführungen in Edelholz mittel poliert oder hell matt.

• Mentioned in
• - - Manufacturers Literature (Telefunken Report '69 mit Messeneuheiten)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
