• Country
• Spain

• Manufacturer / Brand
• Telefunken Radiotécnica Ibérica; Getafe

• Year
• 1961

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 195090

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 0

• Valves / Tubes
• PCC88 PCF80 EF80 EF80 EF80 PL83 ECC82 EF80 PABC80 EL84 ECH81 ECH81 PL81 PCF80 PCL82 PY82 DY86 AW53-80

• Number of Transistors
• 18

• Semiconductors
• OA180

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Rex FE-113 /53T - Telefunken Radiotécnica

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Notes
• Pantalla de 21" @ 90º.
  Selector rotativo 10 canales VHF + 2 de reserva

• Price in first year of sale
• 20,750.00 ESP

• Literature/Schematics (1)
• -- Original prospect or advert (Anuncio La Vanguardia Española octubre 1960)

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
