Ritmo BT-2517

Telefunken Radiotécnica Ibérica; Getafe

Data
Forum
Pictures
Collections

  • Year
  • 1965/1966
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 290109

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 468 kHz; 3 AF stage(s)
  • Tuned circuits
  • 5 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Batteries / addl. power jack / R6: 4 × 1,5 / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
  • Power out
  • 0.315 W (max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Ritmo BT-2517 - Telefunken Radiotécnica
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 170 x 90 x 44 mm / 6.7 x 3.5 x 1.7 inch
  • Notes

  • MW: 550 - 1630 kHz (545 - 184 m.).
    SW: 5,5 - 12,5 MHz.(54,54 - 24 m.).

  • Net weight (2.2 lb = 1 kg)
  • 0.610 kg / 1 lb 5.5 oz (1.344 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
