- Country
- Italy
- Manufacturer / Brand
- Telefunken Italia, Milano
- Year
- 1953 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 195243
Fronte
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 468 kHz
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 125; 140; 160; 180; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: T31 - Telefunken Italia, Milano
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 490 x 270 x 220 mm / 19.3 x 10.6 x 8.7 inch
- Net weight (2.2 lb = 1 kg)
- 5 kg / 11 lb 0.2 oz (11.013 lb)
- Literature/Schematics (1)
- Il Manuale del Radiomeccanico (Vol.3°)
- Author
- Model page created by Eduard Abfalterer. See "Data change" for further contributors.
