VLF - HF Receiver E 1800 A

Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Data
Forum
Pictures
Collections

  • Year
  • 1987 ?
  • Category
  • Commercial Receiver (may include amateur bands)
  • Radiomuseum.org ID
  • 307076

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 40200/200 kHz
  • Wave bands
  • Broadcast, Long Wave and more than two Short Wave bands.
  • Details
  • Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 115; 230 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: VLF - HF Receiver E 1800 A - Telefunken Deutschland TFK,
  • Shape
  • Rack
  • Dimensions (WHD)
  • 433 x 132 x 465 mm / 17 x 5.2 x 18.3 inch
  • Notes

  • Allwellenempfänger E 1800 A: Frequenzbereich 300 Hz - 30 MHz, Betriebsarten A1, A3, J3E, F1, F3, etc., Bandbreiten: in der zweiten Zwischenfrequenz DSP-Selektion, 26 softwaremässig programmierte Filterbandbreiten, dazu 16 phasenoptimierte Filter für digitale Übertragungsarten.

    Neupreis von 40.200 DM bis 52.835 DM im Laufe des Produktionszeitraums.

  • Net weight (2.2 lb = 1 kg)
  • 15 kg / 33 lb 0.6 oz (33.04 lb)
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Martin Bösch. See "Data change" for further contributors.
