FM Stereo Radio Receiving Set R-8000
Teleton Gruppe
- Country
- Europe
- Manufacturer / Brand
- Teleton Gruppe
- Year
- 1975 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 358407
Q= original techn papers
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 20
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Tuned circuits
- 5 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 50-60 Hz, 115; 230 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 6 W (max.)
- from Radiomuseum.org
- Model: FM Stereo Radio Receiving Set R-8000 - Teleton Gruppe
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 400 x 80 x 227 mm / 15.7 x 3.1 x 8.9 inch
- Notes
-
AM/FM Stereophonic Receiver, output power 2x 3 W at 10% THD (both channels operated).
Two loudspeaker systems included, each 200 x 230 x 150 mm, 1.5 kg.
Speaker diameter 16 cm.Transistors and diodes are only listed one per type.
- Net weight (2.2 lb = 1 kg)
- 3.5 kg / 7 lb 11.3 oz (7.709 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Hugo Sneyers. See "Data change" for further contributors.
