• Country
• United States of America (USA)

• Manufacturer / Brand
• Telonic Industries, Telonic Berkeley; Beech Drive, IN, later Laguna Beach and Vista, CA

• Year
• 1962

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 298380

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• 12AX7 6AU6 6AU6 EL84 6CM8 12AX7 EL84 6AF4 6AK5 6AK5 7586 6AU6 12AX7 12AT7 12AU7 12AX7 EL84 6EW6 EL84 6EW6 5651 0A2

• Number of Transistors

• Semiconductors
• 1N2094 1N34A

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 115 or 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• from Radiomuseum.org
• Model: VHF Television Sweep Generator SV-13 - Telonic Industries, Telonic

• Mentioned in
• IETE Journal of research, issue 3, 1962

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
