• Country
• United States of America (USA)

• Manufacturer / Brand
• Templetone Radio Mfg. Corp. (Temple); Mystic, New London, CT

• Year
• 1945 ?

• Category
• Military Receiver

• Radiomuseum.org ID
• 324789

• • Brand: Temple

• Number of Tubes
• 5

• Valves / Tubes
• 1N5GT 1A7GT 1N5GT 1H5GT 3Q5GT

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: BP2-A5 - Templetone Radio Mfg. Corp.

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 330 x 280 x 180 mm / 13 x 11 x 7.1 inch

• Notes

• Radio for army troops.

  MW and Short Wave (6Mhz to 18Mhz).

• Net weight (2.2 lb = 1 kg)
• 4.4 kg / 9 lb 11.1 oz (9.692 lb)
