Service Oszilloskop BM370

• Country
• Czechoslovakia

• Manufacturer / Brand
• Tesla; Praha, Bratislava etc.

• Year
• 1962 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 117083

• • Brand: Supraphon

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• EF80 EF80 EF80 6Z31 7QR20

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 120; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Service Oszilloskop BM370 - Tesla; Praha, Bratislava etc.

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 140 x 225 x 310 mm / 5.5 x 8.9 x 12.2 inch

• Notes
• Service-Klein-Oszillograf. Vertikaleingang 1: 1 Hz - 5 MHz, 50 mV/cm; Vertikaleingang 2: 1 Hz - 200 kHz, 10 mV/cm; Horizontaleingang 10Hz - 200 kHz, 0,5 V/cm.

• Net weight (2.2 lb = 1 kg)
• 5.9 kg / 12 lb 15.9 oz (12.996 lb)

• Mentioned in
• "Radioschau", Heft 4, 1962
