Museum Series TPC-109 Sparton 566 Bluebird Ch= 506 (replica)

• Country
• United States of America (USA)

• Manufacturer / Brand
• Thomas America Corporation; East Brunswick (NJ)

• Year
• 1997

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 182247

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Various materials

• from Radiomuseum.org
• Model: Museum Series TPC-109 Sparton 566 Bluebird Ch= 506 - Thomas America Corporation;

• Shape
• Design Radio or Novelty / Gadget - fancy or unusual shape.

• Dimensions (WHD)
• 16.5 x 16.75 x 8 inch / 419 x 425 x 203 mm

• Notes

• Thomas Museum Series TPC-109

  Sparton 566 Bluebird replica radio, 15 W power consumption, made in China.

  Compare with Crosley CR-37, Spirit of St. Louis LW-119, and other branded similar radios.
