• Country
• Spain

• Manufacturer / Brand
• Thomson Española S.A.; Thomson General Eléctrica; Cedosa; Electa; Setelsa; Madrid

• Year
• 1980 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 317774

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors
• 2SA991 2SC1845 2SA992 2SA733 2SC945 2SB536 2SD381 2SA916 2SC1941 2SK163 2SB705 2SD745 MUPA63H1L TA7318 UAA180

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Power out
• 160 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Amplificador Estereofónico AP-1301 - Thomson Española S.A.; Thomson

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 440 x 100 x 340 mm / 17.3 x 3.9 x 13.4 inch

• Notes

• Thomson Española S.A. Amplificador Estereofónico AP-1301

  Forma conjunto con

  • Cassette Deck   PC-1301W
  • Sintonizador      T  - 1301

  Listado un único semiconductor por tipo

• Net weight (2.2 lb = 1 kg)
• 13 kg / 28 lb 10.1 oz (28.634 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
