Cassette Deck Estereofónico CD-305

• Country
• Spain

• Manufacturer / Brand
• Thomson Española S.A.; Thomson General Eléctrica; Cedosa; Electa; Setelsa; Madrid

• Year
• 1983 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 317905

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 19

• Semiconductors
• 2SD669 2SC945 2SD794 2SC1775 2SC1345 2SC1840 2SC2002 2SD571 2SA733 NE645 CD4001 DN6838 S1RB OA90 1S2473 1SR34 SR535D

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player; Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Cassette Deck Estereofónico CD-305 - Thomson Española S.A.; Thomson

• Shape
• Book-shelf unit.

• Notes

• Thomson Española S.A. Cassette Deck Estereofónico CD-305

  • Para cintas de hierro, cromo y metal

  Véase también:

  • CD-304, similar pero con indicador de nivel con Vúmetros

  Listado un único semiconductor por tipo.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
