Digital Multimeter PDM35
Thurlby Thandar Instruments
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Thurlby Thandar Instruments
- Year
- 1979 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 310973
-
- alternative name: Thandar Electronics || TTI
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 12
- Semiconductors
- BC183 BFR41 BC214 LM3900 CD4007 AY-5-3507 CA3130 1S44 1N4007 BZX5V6 BZX6V2 unknown_Display
- Wave bands
- - without
- Power type and voltage
- Batteries / addl. power jack / PP3: 1 x 9 / 9 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Digital Multimeter PDM35 - Thurlby Thandar Instruments
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 75 x 35 x 155 mm / 3 x 1.4 x 6.1 inch
- Notes
-
Thandar-Sinclair PDM35, 3-1/2 digital multimeter
Each semiconductor type listed once
See also Sinclair PDM35
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
