Frequency Meter PFM200A

Thurlby Thandar Instruments

Data
Forum
Pictures
Collections

  • Year
  • 1981
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 225168
    • alternative name: Thandar Electronics || TTI

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 9
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Frequency Meter PFM200A - Thurlby Thandar Instruments
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 157 x 76 x 32 mm / 6.2 x 3 x 1.3 inch
  • Notes

  • Affichage sur display LED 8 digit.

    Deux gamme de mesures:

    gamme 1: de 20Hz à 10MHz;

    gamme 2: de 5MHz à 200MHz.



    Deux entrées sur prises BNC :

    entrée 1: 0dB, 1MΩ/50pF, sensibilité 10mV rms;

    entrée 2: -20dB, 1MΩ/50pF.



  • Net weight (2.2 lb = 1 kg)
  • 0.170 kg / 0 lb 6 oz (0.374 lb)
  • Source of data
  • - - Manufacturers Literature
  • Author
  • Model page created by Jean Marchal. See "Data change" for further contributors.
