• Country
• Czechoslovakia

• Manufacturer / Brand
• Titan, ES radiotovarna, Praha

• Year
• 1936/1937

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 75320

• Number of Tubes
• 5

• Valves / Tubes
• AK2 AF3 ABC1 AL4 AZ1

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 120/220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Regent-Superhet - Titan, ES radiotovarna, Praha

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 290 x 500 x 300 mm / 11.4 x 19.7 x 11.8 inch

• Notes
• Beleuchteter Senderzeiger mit Glimmröhre.

• Author
• Model page created by Peter Breu. See "Data change" for further contributors.

• Other Models

• Here you find 22 models, 18 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
