UKW-MW-LW Cassetten Recorder TR-605AL

Tobishi Electronic Ind. (Taiwan) Ltd.;Taipei-Hsien / Taiwan

Data
Forum
Pictures
Collections

  • Year
  • 1979 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 309455

 Technical Specifications

  • Number of Transistors
  • 9
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 220 / UM2: 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: UKW-MW-LW Cassetten Recorder TR-605AL - Tobishi Electronic Ind. Taiwan
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 300 x 190 x 70 mm / 11.8 x 7.5 x 2.8 inch
  • Notes

  • TOBISHI TR-605AL MW/LW/UKW CASSETTEN RECORDER

    Batterie-Kontrollanzeige
    Eingebautes Kondensator-Mikrofon
    Auto-Stop, Bandzählwerk
    Gehäuse in Schwarz/Silber

    Sleep function
    Monitor
    DIN Buchse
    Kopfhörerbuchse

    Siehe auch Interfunk Tobishi MW/KW/FM Radio Cassette Tape Recorder TR-605AL

  • Net weight (2.2 lb = 1 kg)
  • 2.4 kg / 5 lb 4.6 oz (5.286 lb)
  • Author
  • Model page created by Eckhard Wegner. See "Data change" for further contributors.
