- Country
- Japan
- Manufacturer / Brand
- Tokai Wireless Co.,Ltd., Tokyo
- Year
- 1965 ??
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 251505
-
- Brand: Million
- Number of Transistors
- 18
- Semiconductors
- Main principle
- Transceiver
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 13,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Power out
- 3 W (max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: TC5007 - Tokai Wireless Co.,Ltd., Tokyo
- Dimensions (WHD)
- 140 x 55 x 205 mm / 5.5 x 2.2 x 8.1 inch
- Notes
-
Ricetrasmettitore per Banda Cittadina (CB) 27 MHz - 23 canali.
4 diodi.
- Net weight (2.2 lb = 1 kg)
- 1.3 kg / 2 lb 13.8 oz (2.863 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
