Transceiver PW-300E
Tokai Wireless Co.,Ltd., Tokyo
- Country
- Japan
- Manufacturer / Brand
- Tokai Wireless Co.,Ltd., Tokyo
- Year
- 1966 ?
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 317961
-
- Brand: Million
- Number of Transistors
- 19
- Semiconductors
- Main principle
- Transceiver
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2.5 W (max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Transceiver PW-300E - Tokai Wireless Co.,Ltd., Tokyo
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 253 x 95 x 120 mm / 10 x 3.7 x 4.7 inch
- Notes
-
X-tals for ch 19 mounted, possibility for 5 X-tal controlled channels RX/TX. VFO RX for 23 channels
- Price in first year of sale
- 820.00 SKr
- Author
- Model page created by Kjell Larsson. See "Data change" for further contributors.
