Stockholm T501
Tonfunk GmbH; Karlsruhe
- Country
- Germany
- Manufacturer / Brand
- Tonfunk GmbH; Karlsruhe
- Year
- 1963/1964
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 108620
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Stockholm T501 - Tonfunk GmbH; Karlsruhe
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 670 x 500 x 300 mm / 26.4 x 19.7 x 11.8 inch
- Notes
- VHF/UHF. Technische Daten wie Violetta 1459, jedoch anderes Gehäuse und andere Bildröhre.
Im VDRG-Handbuch fälschlicherweise A56-16W angegeben.
- Net weight (2.2 lb = 1 kg)
- 32 kg / 70 lb 7.8 oz (70.485 lb)
- Price in first year of sale
- 998.00 DM
- Source of data
- Handbuch VDRG 1963/1964
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
