• Country
• Germany

• Manufacturer / Brand
• Tonfunk GmbH; Karlsruhe

• Year
• 1955/1956

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 17375

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• EC92 ECH81 EF89 EABC80 EL84

• Number of Transistors

• Semiconductors
• B250C75

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Power out
• 4 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Violetta W125Pe - Tonfunk GmbH; Karlsruhe

• Dimensions (WHD)
• 340 x 225 x 180 mm / 13.4 x 8.9 x 7.1 inch

• Notes

• [5. Taxliste Franzis-Verlag, 1957]

  Mit schaltbarer Schallwandbeleuchtung. "Mehrpreis für Frontlampe 4,50 DM"

• Price in first year of sale
• 199.00 DM

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb
