Violetta W200, W200ME

Tonfunk GmbH; Karlsruhe

Data
Forum
Pictures
Collections

  • Year
  • 1952 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 241668

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 472/10700 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)     5 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-125; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Violetta W200, W200ME - Tonfunk GmbH; Karlsruhe
  • Shape
  • Tablemodel, low profile (big size).
  • Notes

  • ACHTUNG: Ein Pol des Lichtnetzes ist mit dem Chassis verbunden.
    Flanken-Demodulator für UKW/FM.

    Suffix M = mag.Auge. Suffix "E" ist noch unklar.
