Compact Disc Digital Audio Changer XR-9057

Toshiba Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1987 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 289190
    • alternative name: Shibaura Engineering Works
    • Brand: Tokyo Shibaura

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact Disc Digital Audio Changer XR-9057 - Toshiba Corporation; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 420 x 107 x 327 mm / 16.5 x 4.2 x 12.9 inch
  • Notes

  • Compact Disc Digital Audio Changer Model Toshiba XR-9057.
    Disc format: CD (6 disc multi play)
    Frequency response: 5Hz to 20kHz
    Dynamic range: 94dB
    Channel separation: 90dB
    Total harmonic distortion: 0.004%
    Line output: 2V
    Power Supply:
    TE - European Model - 220VAC 50 Hz
    TA - U.S.A. Model - 120VAC 60Hz
    TC - Canadian Model - 120VAC 60Hz
    TU - U.K. Model - 240VAC 50Hz
    Power Consumption 11 Watts


  • Net weight (2.2 lb = 1 kg)
  • 5.4 kg / 11 lb 14.3 oz (11.894 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
