FM/AM 2-Band Stereo Music System SM-200

Toshiba Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1983
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 231143
    • alternative name: Shibaura Engineering Works
    • Brand: Tokyo Shibaura

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Record Player + Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110-127; 120; 220-240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 26 W (max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: FM/AM 2-Band Stereo Music System SM-200 - Toshiba Corporation; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 450 x 134 x 389 mm / 17.7 x 5.3 x 15.3 inch
  • Notes

  • Toshiba Stereo Music System Model SM-200.
    Frequency Range: FM 88 - 108MHz, AM 525 - 1605kHz.
    2 Speed (33 and 45 rpm) automatic turntable, Replace Stylus N-21D.
    Synchronous Rec Operation, 3 Digit Analog Counter, Auto Stop.
    Bass- and Treble Control, Mic- , Phones Input, Stereo- Mono Switch, Dust Cover.

    Two variants: SM-200, SM-200M

  • Net weight (2.2 lb = 1 kg)
  • 5.1 kg / 11 lb 3.7 oz (11.233 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
