FM/SW/MW/LW Radio Cassette Recorder RT-140S
Toshiba Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Toshiba Corporation; Tokyo
- Year
- 1982 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 329185
-
- alternative name: Shibaura Engineering Works
- Brand: Tokyo Shibaura
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 50Hz, 220-240 / D: 6 x 1.5 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: FM/SW/MW/LW Radio Cassette Recorder RT-140S - Toshiba Corporation; Tokyo
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 490 x 220 x 135 mm / 19.3 x 8.7 x 5.3 inch
- Notes
-
2-Way speaker system, Cassette auto reverse, umschaltbar mono, stereo, wide. Anschluß für Ohrhörer, externe Mikrofonanschlüsse. Kanal rechts und Kanal links, DIN-5-pol Überspielbuchse.
- Net weight (2.2 lb = 1 kg)
- 3.3 kg / 7 lb 4.3 oz (7.269 lb)
- Author
- Model page created by Wolfgang Lill. See "Data change" for further contributors.
