Graphic Equalizer EQ-E36
Toshiba Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Toshiba Corporation; Tokyo
- Year
- 1985
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 246150
-
- alternative name: Shibaura Engineering Works
- Brand: Tokyo Shibaura
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 18
- Semiconductors
- 2SA1015 2SA1015 2SA1015 2SA1015 2SA1015 2SA1015 2SA1015 2SA1015 2SC2878 2SC1815 2SC1815 2SC1815 2SC1815 2SC1815 2SC1815 2SC1815 2SC1815 2SC2878 NJM4558 NJM4558
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 120; 220; 240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Graphic Equalizer EQ-E36 - Toshiba Corporation; Tokyo
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 420 x 87 x 225 mm / 16.5 x 3.4 x 8.9 inch
- Notes
-
Toshiba Graphic Equalizer EQ-E36, separate controls for 7 bands, two channels.
Band center frequencies: 60, 160, 400 Hz; 1, 2,4, 6, 15 kHz.
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Author
- Model page created by Karl-Heinz Entrich † 7.21. See "Data change" for further contributors.
