TR-193

Toshiba Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1958
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 121685
    • alternative name: Shibaura Engineering Works
    • Brand: Tokyo Shibaura

 Technical Specifications

  • Number of Transistors
  • 4
  • Semiconductors
  • Main principle
  • Superheterodyne (common); Reflex
  • Tuned circuits
  • 5 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.25 inch = 5.7 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: TR-193 - Toshiba Corporation; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 2.63 x 4.125 x 1.37 inch / 67 x 105 x 35 mm
  • Notes

  • Reflex circuit, nick name "Lace".

    Toshiba Model TR-193.  Made in Japan.  Labeled as 'Reflex' since the output transistor does a double duty of first extracting the audio signal from radio frequency and then passing the audio signal again to amplify it before the audio signal reaches the loudspeaker.

    Some versions of TR-193 have five transistors rather than four.

    Toshiba coded the date of manufacture into a radio's serial number.  The 1st digit is the final digit of year of manufacture (9 for 1959).  The 2nd and 3rd digits are the month of manufacture.  The 5 remaining digits are the base serial number.

    Available in Navy Blue with Gray or Red with White

    Complete with Battery and Genuine Leather Carrying Case

  • Net weight (2.2 lb = 1 kg)
  • 0.270 kg / 0 lb 9.5 oz (0.595 lb)
  • Price in first year of sale
  • 24.95 USD
