• Country
• United States of America (USA)

• Manufacturer / Brand
• Clarion, Transformer Corp. of America (TCA); Chicago, IL

• Year
• 1933 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 170806

• • Brand: Clarion

Click on the schematic thumbnail to request the schematic as a free document.

• from Radiomuseum.org
• Model: 120-139 - Clarion, Transformer Corp. of

• Notes
• Warning: 120-139 is mentioned in Rider's vol.2-4 and 2-11. It may be mistaken for a separate model, but obviously there are only the models 120 and 139.

• Circuit diagram reference
• Rider's Perpetual, Volume 2 = 1932 (Models 1931/1932)

• Literature/Schematics (1)
• Riders 2-4, 11

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
