621-26 Ch= 412M6
Trav-Ler Karenola Radio & Television Corp.(Travler); Chicago
- Country
- United States of America (USA)
- Manufacturer / Brand
- Trav-Ler Karenola Radio & Television Corp.(Travler); Chicago
- Year
- 1956 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 277873
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 21
- Valves / Tubes
- 6BQ7A 6J6 6CB6 6CB6 6AU6 6AL5 6AH6 6AU6 6AL5 6AV6 6V6GT 6C4 6SN7GT 6C4 6S4 6SN7GT 6CU6 6W4GT 1B3GT 5U4GA 21AUP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 110-120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: 621-26 Ch= 412M6 - Trav-Ler Karenola Radio &
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
The TRAV-LER model 621-26 is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13, equipped with VHF-tuner TA-18, chassis 412M6 and picture tube 21AUP4A. 2 speakers 6x9 inch.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 334 Folder 10 dated 10-56)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
