AM/FM Stereo Receiver KR-3600L

Kenwood, Trio-Kenwood Inc.; Komagane

Data
Forum
Pictures
Collections

  • Year
  • 1973
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 282115
    • alternative name: Trio Corp.
    • Brand: Jennen

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 50/60Hz; 110; 120; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AM/FM Stereo Receiver KR-3600L - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 500 x 140 x 302 mm / 19.7 x 5.5 x 11.9 inch
  • Notes

  • Trio Kenwood AM/FM Stereo Receiver Model KR-3600L.
    Power output: 22 watts per channel into 8Ω (stereo)
    Frequency response: 20Hz to 50kHz
    Total harmonic distortion: 0.8%
    Damping factor: 35
    Input sensitivity: 2.5mV (MM), 150mV (line)
    Signal to noise ratio: 70dB (MM), 90dB (line)
    Speaker load impedance: 4Ω to 16Ω
    Bass- & Treble Control
    High Filter
    Loudness Control
    Power Consumption 180 Watts
    Wooden Side Panels

  • Net weight (2.2 lb = 1 kg)
  • 9 kg / 19 lb 13.2 oz (19.824 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
