Compact Disc Player DP-3020

Kenwood, Trio-Kenwood Inc.; Komagane

Data
Forum
Pictures
Collections

  • Year
  • 1988–1990 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 306041
    • alternative name: Trio Corp.
    • Brand: Jennen

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • DSP, Digital Signal Processor
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 110-120 or 220 or 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact Disc Player DP-3020 - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 440 x 108 x 262 mm / 17.3 x 4.3 x 10.3 inch
  • Notes

  • Frequency Response :  4 Hz - 20 kHz ± 1.0 dB
    Signal to Noise Ratio : More than 90 dB
    Total Harmonic Distortion : 0.01% at 1 kHz
    Channel Separation : More than 85 dB at 1 kHz
    Output : Line 1.2 volts, Headphone jack 20 mW (16Ω)
    2 Kenwood System Control terminals.
    With remote-control.

    Anschlüsse: Input=cinch; 2 Buchsen für System-Control
    Frequenzbereich: 4Hz bis 20.000Hz

    Units shipped to USA and Canada are designed to operate on 120 volts AC, those to UK and Australia 240 volts AC and those to Europe 220 volts AC.

  • Net weight (2.2 lb = 1 kg)
  • 3.8 kg / 8 lb 5.9 oz (8.37 lb)
  • Mentioned in
  • - - Manufacturers Literature (Instruction Manual for DP-3020 and DP-2020)
