Compact Disc Stereo System with Radio FM/AM RXD-C2L

Kenwood, Trio-Kenwood Inc.; Komagane

Data
Forum
Pictures
Collections

  • Year
  • 2000 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 314742
    • alternative name: Trio Corp.
    • Brand: Jennen

 Technical Specifications

  • Number of Transistors
  • 43
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Other Combination - see Notes; Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Compact Disc Stereo System with Radio FM/AM RXD-C2L - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 270 x 305 x 310 mm / 10.6 x 12 x 12.2 inch
  • Notes
    • Stereo compact disk player with auto reverse double deck cassette recorder/player and radio AM/FM.
    • Input for external aux with volume regulator.
    • Output for active "Super Woofer".
    • Cassette dubbing high/normal speed.
    • Jack for earphones.
    • Input for stereo microphone.
    • IC and transistors listed once for type.
    • Remote controller



  • Net weight (2.2 lb = 1 kg)
  • 5 kg / 11 lb 0.2 oz (11.013 lb)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
