Compact Disc Player DP-3090

Kenwood, Trio-Kenwood Inc.; Komagane

Data
Forum
Pictures
Collections

  • Year
  • 1997
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 295053
    • alternative name: Trio Corp.
    • Brand: Jennen

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 220/240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact Disc Player DP-3090 - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 440 x 127 x 366 mm / 17.3 x 5 x 14.4 inch
  • Notes

  • CD Player with D.R.I.V.E. noise modulator 3 cd order dual 1- bit DAC, digital oversampling filter 8X, CCRS aut/recording  cd cassette recorder, center mechanism, cd time editing, random reproduction, search for peacks on cd, headphones out, remote control, frequency response 4 Hz-20 kHz +- 0,5 dB, signal noise ratio » 100 dB, total harmonic distortion « 0,006 %, channels separation » 95 dB, crying & floating  imeasurable, output  digital optic -15-21 dBm.

  • Net weight (2.2 lb = 1 kg)
  • 4.8 kg / 10 lb 9.2 oz (10.573 lb)
  • Mentioned in
  • Catalogues Kenwood 1997, Model Page 24
  • Author
  • Model page created by Manuel Albano Neves. See "Data change" for further contributors.
