Stereo Double Cassette Deck KX-W4080

Kenwood, Trio-Kenwood Inc.; Komagane

Data
Forum
Pictures
Collections

  • Year
  • 1997
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 295036
    • alternative name: Trio Corp.
    • Brand: Jennen

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 220/240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Double Cassette Deck KX-W4080 - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 440 x 134 x 367 mm / 17.3 x 5.3 x 14.4 inch
  • Notes

  • Cassette recording/player system,double autoreverse and dolby HX-PRO, expansion limit dolby B/C, double-autoreverse mechanism totally logical , relay recording, MPX filter switch, bias automatic and tuning bias, ccrd aut/copy CD, copy at high speed, controle remoto system, head rigid permaloi,1+2, 1+1 motors, full logic mechanism, dpss,atsc, aut/polarization, ccrs only B, sincronized recording, copy cassette to cassette 2 speeds, recording and player timer, heads :recording and player, erasing double ferrite ferrite, motors electronic controled, frequency response type l 30Hz-18 kHz +- 3dB, type ll 30Hz-18 kHz +- 3dB, signal noise ratio  : dolby C on 75 dB  type ll, dolby B on 68 dB type ll, dolby off 59 type ll, total harmonic distortion (metal)  « 1,2% type ll, sensitivity/impedance : line 122 mV/47 kohms, level/impedance output : line 2   775 mV/1 kohms, headphones    0,5mw/32 ohms, crying floating WRMS 0,07%, remote control.

  • Net weight (2.2 lb = 1 kg)
  • 4.6 kg / 10 lb 2.1 oz (10.132 lb)
  • Mentioned in
  • Catalogues Kenwood 1997, model page 26
  • Author
  • Model page created by Manuel Albano Neves. See "Data change" for further contributors.
