Stereo Cassette Deck KX-3080

Kenwood, Trio-Kenwood Inc.; Komagane

Data
Forum
Pictures
Collections

  • Year
  • 1997
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 294998
    • alternative name: Trio Corp.
    • Brand: Jennen

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 220/240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Cassette Deck KX-3080 - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 440 x 124 x 374 mm / 17.3 x 4.9 x 14.7 inch
  • Notes

  • Recorder and Player cassette, dolby HX-PRO, dolby B/C noise reduction, dolby HX-Pro  limit expansion for clear treble, filter MPX, 2 motors, motorized cassette loading, functions of the direct program search system, cassette tape aut/seletor , remote controlable system, dolby hx-pro , mechanism full logic, DPSS, ATSC, sincronized recording, headphones in, AC-bias current 105 kHz, heads record/player : head permeable alloy, erasing head: double ferrit ferrit, 2 motors DC electronic control, frequençy response : type l 20Hz- 18 kHz +-3 dB, type ll 20 Hz-18 kHz +- 3 dB, type iV 20 Hz-19 kHz +- 3dB, signal noise ratio : dolby C on 74 dB type lV, dolby B on 67 dB type lV, dolby off 59 dB type lV, total harmonic distortion (metal) « 1,7% (315 Hz), sensitivity/impedance : line 100 mV/34 kohms, level/impedance output : line 2  775 mV/1Kohms, headphones x1 0,5 mW/32 ohms, crying  floating WRMS 0,07%, remote control.

  • Net weight (2.2 lb = 1 kg)
  • 4.6 kg / 10 lb 2.1 oz (10.132 lb)
  • Mentioned in
  • Catalogues Kenwood 1997,Model Page 26
  • Author
  • Model page created by Manuel Albano Neves. See "Data change" for further contributors.
