• Country
• Japan

• Manufacturer / Brand
• Kenwood, Trio-Kenwood Inc.; Komagane

• Year
• 1985 ??

• Category
• Power supply/conditioner or battery or charger

• Radiomuseum.org ID
• 154500

• • alternative name: Trio Corp.
  • Brand: Jennen

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 120; 220; 240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Power supply PS-430 - Kenwood, Trio-Kenwood Inc.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 173 x 95 x 245 mm / 6.8 x 3.7 x 9.6 inch

• Notes
• Kenwood Power Supply PS-430.
  Output voltage: 13.8 V; Output current: 20 A (25 % duty cycle), 15 A (50 % duty cycle), Continuous load current = 10 A.

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
