Solid State Stereo Amplifier TK-250
Kenwood, Trio-Kenwood Inc.; Komagane
- Country
- Japan
- Manufacturer / Brand
- Kenwood, Trio-Kenwood Inc.; Komagane
- Year
- 1967
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 150702
-
- alternative name: Trio Corp.
- Brand: Jennen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 19
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 40 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Solid State Stereo Amplifier TK-250 - Kenwood, Trio-Kenwood Inc.;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 330 x 110 x 245 mm / 13 x 4.3 x 9.6 inch
- Notes
- Stereo-Vollverstärker mit 2 x 20 Watt Sinus an 8 Ohm.
19 Transistoren, 7 Dioden, 2 Thermistoren.
- Net weight (2.2 lb = 1 kg)
- 6.5 kg / 14 lb 5.1 oz (14.317 lb)
- Source of data
- -- Collector info (Sammler)
- Literature/Schematics (1)
- High Fidelity Jahrbuch 1967/68 Seite 124
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
