HF SSB Transceiver TS-120V

• Country
• Japan

• Manufacturer / Brand
• Kenwood, Trio-Kenwood Inc.; Komagane

• Year
• 1978 ?

• Category
• Amateur TRX: Transmitter/Receiver (and Transceiver)

• Radiomuseum.org ID
• 90257

• • alternative name: Trio Corp.
  • Brand: Jennen

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 100

• Semiconductors

• Main principle
• Transceiver

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 13,8 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: HF SSB Transceiver TS-120V - Kenwood, Trio-Kenwood Inc.;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 241 x 94 x 235 mm / 9.5 x 3.7 x 9.3 inch

• Notes

• Kenwood HF SSB/CW Transceiver TS-120V.

  Final Power input:

  • SSB: 25 W PEP
  • CW: 20 W

  Frequency ranges:

  • 3.5-4.0 MHz
  • 7.0-7.5 MHz
  • 14.0-14.5 MHz
  • 21.0-21.5 MHz
  • 28.0-29.7 MHz
  • RX only 15.0-15.5 MHz for WWV

  VOX, NB, RIT, digital readout.

• Net weight (2.2 lb = 1 kg)
• 4.9 kg / 10 lb 12.7 oz (10.793 lb)
