TW-4100E
Kenwood, Trio-Kenwood Inc.; Komagane
- Country
- Japan
- Manufacturer / Brand
- Kenwood, Trio-Kenwood Inc.; Komagane
- Year
- 1987
- Category
- Amateur TRX: Transmitter/Receiver (and Transceiver)
- Radiomuseum.org ID
- 187813
-
- alternative name: Trio Corp.
- Brand: Jennen
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet, double/triple conversion; ZF/IF 30825/455 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 13,8 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2.2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: TW-4100E - Kenwood, Trio-Kenwood Inc.;
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 150 x 50 x 200 mm / 5.9 x 2 x 7.9 inch
- Notes
- Kenwood VHF/UHF-Mobilfunkgerät TW-4100E.
Frequenzbereiche: 144–146 MHz und 430–440 MHz; Betriebsart: F3E (FM); Pout: 45 W auf 2 m, 35 W auf 70 cm.
10 Speicher. Stromaufnahme: max. 10 A.
- Net weight (2.2 lb = 1 kg)
- 1.8 kg / 3 lb 15.4 oz (3.965 lb)
- Mentioned in
- Beam Amateurfunk-Geräteführer '90
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
